The LM317 is a versatile, adjustable voltage regulator designed to provide a stable output voltage that can be set anywhere between 1.25V and 37V, making it ideal for a wide range of applications. This robust regulator can supply up to 1.5A of load current with excellent line and load regulation. Its easy-to-use design and high performance make it a popular choice for power supply projects, battery chargers, and other electronic applications requiring precise voltage control.
Technical Specifications:
- Model: LM317
- Output Voltage Range: 1.25V to 37V (adjustable)
- Output Current: 1.5A (max)
- Input Voltage: 3V to 40V
- Line Regulation: 0.01%/V (typical)
- Load Regulation: 0.1% (typical)
- Temperature Range: 0°C to +125°C
- Package Type: TO-220
Features:
- Adjustable Output Voltage: Easily set the output voltage from 1.25V to 37V using two external resistors.
- High Current Capability: Provides up to 1.5A of output current.
- Excellent Regulation: Maintains stable output voltage under varying line and load conditions.
- Thermal Overload Protection: Automatically shuts down the regulator if the internal temperature exceeds safe limits.
- Short-Circuit Protection: Safeguards against output short circuits.
- Safe Operating Area Protection: Ensures reliable operation under all conditions.
Applications:
- Power supplies
- Battery chargers
- Adjustable power sources
- Precision current regulators
- Voltage regulation in electronic circuits
The LM317 Adjustable Voltage Regulator is a reliable and flexible solution for providing precise voltage control in a variety of electronic applications. Its robust design and extensive protection features ensure dependable operation in demanding environments
Package includes:
- 1x LM317 Voltage Regulator – Adjustable
