6Pin 5A Metal Toggle SPDT Switch

The 6-Pin Metal Toggle SPDT (Single Pole Double Throw) Switch is a durable and reliable component designed for a wide range of applications. Its robust metal construction and easy-to-use toggle mechanism make it perfect for both industrial and consumer electronics projects. Whether you need to control circuits, switch between modes, or manage power, this toggle switch offers versatility and dependability.

Key Features

• Sturdy Construction: Made from high-quality metal, ensuring durability and long-term use in demanding environments.
• SPDT Configuration: Single Pole Double Throw functionality allows you to control two different circuits, providing versatility in switching applications.
• 6-Pin Design: Easy to wire and configure, with clearly labeled pins for straightforward installation.
• Toggle Mechanism: Smooth and reliable toggle action for consistent operation.
• Panel Mount: Designed for panel mounting, providing a secure and stable installation.

Specifications

• Switch Type: SPDT (Single Pole Double Throw)
• Contact Rating: 6A at 125V AC, 5A at 250V AC
• Operating Voltage: Up to 250V AC
• Current Rating: 6A at 125V AC,5A at 250V AC
• Pin Configuration: 6-pin (3 pins for each pole)
• Material: Metal body and toggle lever
• Mounting Type: Panel mount with nut and washer for secure attachment
• Operating Temperature: -20°C to +85°C
• Toggle Life: 50,000 cycles

Applications

• Industrial Control: Ideal for machinery and equipment control in industrial settings.
• Consumer Electronics: Suitable for use in audio equipment, home appliances, and DIY projects.
• Automotive: Can be used to control lighting, accessories, and other circuits in vehicles.
• Aerospace: Reliable for use in aircraft and spacecraft control panels.
• Marine: Perfect for marine applications due to its robust construction.

Installation and Usage

1. Mounting: Drill a hole in your panel or enclosure to match the diameter of the switch’s threaded mounting shaft.
2. Wiring: Connect the switch’s pins according to your circuit requirements. The center pin is the common terminal, while the outer pins are the normally open (NO) and normally closed (NC) terminals.
3. Securing: Secure the switch in place using the included nut and washer.
4. Operation: Flip the toggle to switch between the connected circuits or modes.

Why Choose Our 6-Pin Metal Toggle SPDT Switch?

This 6-Pin Metal Toggle SPDT Switch is the ideal choice for those who need a reliable and durable switch for their projects. Its robust metal construction ensures long-lasting performance, while its SPDT configuration provides versatile control options. Easy to install and use, this switch is perfect for a wide range of applications, from industrial control systems to consumer electronics.

Enhance your projects with the dependable performance of our 6-Pin Metal Toggle SPDT Switch. Order now and experience the difference in quality and reliability!

Package includes:

1 X 6-Pin Metal Toggle SPDT Switch
