DG (Deep Cycle GEL)series is pure GEL battery with 15~20 years floating design life, it is ideal for standby or frequent cyclic discharge applications under extreme environments.By using strong grids, high purity lead and patented Gel electrolyte, the DGseries offers excellent recovery after deep discharge under frequent cyclic discharge use, and can deliver 400 cycles at 100% DOD. Suitable for solar, CATV, marine, RV, and deep discharge UPS,communication , and telecommunication , etc.
Technical specification
| Model | Nominal Voltage           （V） | Capacity | Dimension | Weight | Terminal | |||||||||
| （Ah） | Length | Width | Height | Total Height | （Kg） | （Lbs） | ||||||||
| mm | inch | mm | inch | mm | inch | mm | inch | |||||||
| DG12-26 | 12 | 100 | C20/1.75VPC | 323 | 12.19 | 172 | 6.77 | 215 | 8.46 | 220 | 8.66 | 29.0 | 17.86 | F3(M5) / F5(M8)/T12(M8) |
